نظرة عامة على المشروع

Syria – Iraq 400 KV interconnection / Siemens PTD:

Adra Substation:
Construction of new 400 KV conventional substations consisting of:
1 Nos. new 400 KV Diameter (3 OHL feeders and 2 transformer feeders). Associated auxiliary works to comply with new project needs.

Jandar :
Construction of new 400 KV conventional substations consisting of
1 Nos. new 400 KV Diameter to reach 5 diameters (3 OHL feeders). Associated auxiliary works to comply with new project needs.

Nasserieh:
Construction of new 400 KV Conventional substation consisting of:
3 Nos. 400 KV Diameter (2 OHL feeders and 1 transformer feeder), 1 Nos. 400/ 230 KV, 300MVA power transformers.
1 Nos.20 KV, 20 MVAr capacitors Bank,
1 Nos. 200.4/ KV, 800 KVA Auxiliary transformer.
Associated auxiliary works.

Taym:
Construction of new 400 KV Conventional substation consisting of:
3 Nos. 400 KV Diameter (2 OHL feeders and 1 transformer feeder), 1 Nos. 400/ 230 KV, 300MVA power transformers.
1 Nos. 20 KV, 20 MVAr shunt reactors and
1 Nos. 200.4/ KV, 800 KVA Auxiliary transformer.
Associated auxiliary works.

Palmyra:
Construction of new 400KV Conventional substation consisting of:
2 Nos. 400 KV Diameter (2 OHL feeders and 1 transformer feeder), 1 Nos. 400/ 230 KV, 300MVA power transformers.
1 Nos.20 KV, 20MVAr capacitors Bank and
1 Nos. 200.4/ KV, 800 KVA Auxiliary transformer.
Associated auxiliary works.
